TrafficTuff System

100% solids, epoxy pedestrian/vehicular system which provides surface protection to concrete substrates with no waterproofing requirements

TrafficTuff is a non-waterproofing, textured system designed to provide concrete surface protection. The system offers a solid color, pigmented top coat.

Product Specifications
Application Methods
Product Literature
Technical Documents
FAQs

System Overview

Neogard TrafficTuff provides you with an easy-to-install, two-coat traffic coating solution. It uses our proven 70714/70715-09 epoxy base coat and a choice of urethane or epoxy topcoats, depending on the application. Our FC7540/FC7964 fast-cure urethane can be used for exterior, UV-exposed applications. A variety of standard colors is available, and the 7992-U aggregate provides texture for a solid grip.

Selected Physical Properties

Product	Description	Test Method	Results
70714/70715 epoxy	Taber Abrasion	ASTM D4060	25 mg (1,000 CS-17)
70714/70715 epoxy	Shore D	ASTM D2240	78
70714/70715 epoxy	Flexural Strength/Modulus	ASTM D790	3,180/57,700 psi
FC7510/FC7961 urethane	Taber Abrasion	ASTM D4060	55 mg (1,000 CS-17)
FC7540/FC7964 urethane	Taber Abrasion	ASTM D4060	95 mg (1,000 CS-17)

Consult Neogard Product Data Sheets and Guide Specifications for a complete list of physical properties.

Use Area:

Pedestrian

Type:

Epoxy

Features:

High performance properties
Visually pleasing
Low to no odor

Benefits:

Offers outstanding durability
Enhances appearance of application area
Can be used in areas near public

Ask us about Traffic Tuff

Our Neogard Experts team is glad to tell you how Traffic Tuff is the best coating system to protect your investment.

1-833-443-6735

TrafficTuff System Build

Before application, always check Neogard Product Data Sheets and Guide Specifications for mixing instructions and other important information.

TrafficTuff

Coat	Product	Coverage Rate	Mils WFT/DFT
2 - Topcoat	FC7540/FC7964 FC7510/FC7961 70714/70715	120 sf/gal 133 sf/gal 133 sf/gal	13/12 12/12 12/12
1 - Base	70714/70715-09 7992-U aggregate	100 sf/gal 15 lbs/100 sf	16/16

Product Literature

Files may be downloaded individually or in a submittal package. Choose a language to select a file. Select one file and click the download button to the right, or select multiple files and click the “Download Selected” button below.

Technical Documents

selected

Safety Data Sheets (SDS)

FAQs

How long does TrafficTuff need to cure before opening to vehicular traffic?

Typically the system may be opened to traffic 24 hours after installation. In cold temperature
it may require 36-48 hours.

Can TrafficTuff be applied to slab on grade concrete?

Yes. In some conditions it is best to check moisture vapor transmission (MVT) prior to
applying.

What is the minimum temperature at which TrafficTuff can be applied?

Temperature must be 50°F/10°C and rising.

Can Traffic Tuff be topcoated?

Yes. The system can receive a urethane or epoxy top coat.

You can trust Traffic Tuff in your next project

High-performance protection tested under the harshest environments. Traffic Tuff is an epoxy two-coat system designed to enhance the appearance of any concrete surface while standing the potential damage of pedestrian or light vehicular traffic.
