RTS Pedestrian Traffic System

Heavy-duty PMMA/PUMA system for pedestrian traffic surfaces

RTS Pedestrian System is a rapid-curing, PMMA/PUMA-based waterproofing system that offers the utmost in durability to withstand severe conditions and pedestrian traffic on balconies, recreational areas, and other high-traffic surfaces.

Product Specifications
Application Methods
Product Literature
Technical Documents
FAQs

System Overview

The Neogard RTS Pedestrian System uses PMMA/PUMA technology to provide a system which can handle the toughest environments, can return to service as soon as one hour after installation, and can be installed in temperatures down to 20°F/-7°C. The high elongation properties of the PMMA/PUMA materials do not require reinforcement typical of other similar systems.

Two versions of the system are specified: System A is a waterproofing system, and System B is ideal for applications not over occupied space. Regardless of the conditions, our RTS Pedestrian System will provide the protection your decks need.

Selected Physical Properties

Product	Description	Test Method	Results
RTS Pedestrian System	Dynamic Coefficient of Friction	ASNI A137.1	0.77 dry, 0.73 wet
200 RTS Membrane	Elongation	ASTM D638	282%
200 RTS Membrane	Low-Temperature Crack Bridging	ASTM C1305	Pass at 40/60/80 mils
300 RTS Flexible Body Coat	Elongation	ASTM D638	204%
300 RTS Flexible Body Coat	Low-Temperature Crack Bridging	ASTM C1305	Pass at 40/60/80 mils
400 RTS Topcoat	Shore A/D	ASTM D2240	95/60
400 RTS Topcoat	Taber Abrasion	ASTM D4060	33 mg/1,000 CS-17

Consult Neogard Product Data Sheets and Guide Specifications for a complete list of physical properties.

Use Area:

Pedestrian Traffic

Type:

PMMA/PUMA

Features:

Excellent elongation
Rapid cure
High abrasion resistance
Cold weather application

Benefits:

Provides crack bridging/waterproofing without need for reinforcement
Can be opened to service one hour after installation
Outstanding durability
Extends coating season

Ask us about RTS Pedestrian System

Our Neogard Experts team is glad to tell you how RTS Pedestrian System is the best coating system to protect your investment.

1-833-443-6735

RTS Pedestrian System build

Before application, always check Neogard Product Data Sheets and Guide Specifications for mixing instructions and other important information. For RTS PMMA/PUMA systems, also refer to the BPO Initiator Dosage Chart (included on RTS 200, 300, and 400 Product Data Sheets).

System A

System B

RTS Pedestrian System A

Coat	Product	Coverage Rate	Mils DFT
4 - Topcoat	400 RTS	64 sf/gal	25
3 - Flexible Body	300 RTS + 86364 20/40 sand aggregate	80 sf/gal To refusal	17
2 - Membrane	200 RTS	26 sf/gal	60
1 - Primer	100 RTS	90 sf/gal	17

RTS Pedestrian System B

Coat	Product	Coverage Rate	Mils DFT
3 - Topcoat	400 RTS	64 sf/gal	25
2 - Flexible Body	300 RTS + 900 RTS filler + 7992 aggregate	26 sf/gal 10 lb/gal of 300 RTS To refusal	60
1 - Primer	100 RTS	90 sf/gal	17

Safety Data Sheets (SDS)

FAQs

How long do RTS systems need to cure before opening to traffic?

The system can be opened to traffic one hour after top coat has been applied, even in cold temperatures.

What type concrete curing compounds can be used with RTS systems?

Water cure concrete or use a sodium silicate curing compound. Acrylic or other film forming compounds will create issues with bonding and must be removed.

What is the minimum temperature at which RTS systems can be applied?

RTS materials can be applied in temperatures as low as 20°F/-7°C. With special instructions it can be applied in colder temperatures.

Can RTS systems be applied during hot temperatures?

RTS materials can be applied hot weather; however, avoid applying in direct sunlight.

You can trust RTS Pedestrian System in your next project

High-performance protection tested under the harshest environments. RTS Pedestrian System is a rapid-curing PMMA/PUMA based system that provides waterproofing protection and the utmost in durability to withstand the harshest service.
