RTS Under Tile System

PMMA/PUMA system providing moisture protection for applications under thinset tile

RTS Under Tile System is a non-reinforced waterproofing system designed for use on applications that are to receive tile. The high elongation properties do not require reinforcement typical of other similar systems.

Product Specifications
Application Methods
Product Literature
Technical Documents
FAQs

System Overview

The Neogard RTS Under Tile System uses PMMA/PUMA technology to provide a system which can return to service as soon as one hour after installation, and can be installed in temperatures down to 20°F/-7°C. The high elongation properties of the PMMA/PUMA materials do not require reinforcement typical of other similar systems.

The system features our RTS 200 Membrane and our 300 RTS Flexible Body Coat with 7992 sand aggregate. The system provides excellent waterproofing performance and provides the grip necessary for thin-set tile installation.

Selected Physical Properties

Product	Description	Test Method	Results
200 RTS Membrane	Elongation	ASTM D638	282%
200 RTS Membrane	Low-Temperature Crack Bridging	ASTM C1305	Pass at 40/60/80 mils
300 RTS Flexible Body Coat	MVT	ASTM E96	143.0 mg m² 1 hour, 3.43 g m² 24 hours
300 RTS Flexible Body Coat	Elongation	ASTM D638	204%
300 RTS Flexible Body Coat	Low-Temperature Crack Bridging	ASTM C1305	Pass at 40/60/80 mils

Consult Neogard Product Data Sheets and Guide Specifications for a complete list of physical properties.

Use Area:

Under Tile

Type:

PMMA/PUMA

Features:

Excellent elongation
Rapid cure
Aggregate-loaded topcoat
Cold weather application

Benefits:

Provides crack bridging/waterproofing without need for reinforcement
Can be opened to service one hour after installation
Excellent adhesion of thin-set systems
Extends coating season

Ask us about RTS Under Tile System

Our Neogard Experts team is glad to tell you how RTS Under Tile System is the best coating system to protect your investment.

1-833-443-6735

RTS Under Tile System Build

Before application, always check Neogard Product Data Sheets and Guide Specifications for mixing instructions and other important information. For RTS PMMA/PUMA systems, also refer to the BPO Initiator Dosage Chart (included on RTS 200, 300, and 400 Product Data Sheets).

RTS Under Tile

RTS Under Tile System

Coat	Product	Coverage Rate	Mils DFT
3 - Flexible Body	300 RTS + 7992 aggregate	80 sf/gal To refusal	20
2 - Membrane	200 RTS	26 sf/gal	60
1 - Primer	100 RTS	90 sf/gal	17

Product Literature

Files may be downloaded individually or in a submittal package. Choose a language to select a file. Select one file and click the download button to the right, or select multiple files and click the “Download Selected” button below.

Technical Documents

selected

Safety Data Sheets (SDS)

FAQs

How long does the RTS Under Tile System need to cure before installing setting bed material?

Setting bed material can be applied one hour after the Flexible Body Coat (300 RTS) has been applied, even in cold temperatures.

What type concrete curing compounds can be used with RTS systems?

Water cure concrete or use a sodium silicate curing compound. Acrylic or other film forming compounds will create issues with bonding and must be removed.

What is the minimum temperature at which RTS systems can be applied?

RTS materials can be applied in temperatures as low as 20°F/-7°C. With special instructions it can be applied in colder temperatures.

Can RTS systems be applied during hot temperatures?

RTS materials can be applied hot weather; however, avoid applying in direct sunlight.

You can trust RTS Under Tile System in your next project

High-performance protection tested under the harshest environments. RTS Under Tile System is a rapid-curing PMMA/PUMA based system that provides waterproofing protection and the utmost in durability to withstand the harshest service.
